Dive compressor C-NITROX 660

nitroxscrewelectric

C-NITROX 660 C-Nitrox 660 is a Heavy Duty industrial screw compressor that delivers air at a pressure of 12 bar to two Permea membranes that separate nitrogen and oxygen, up to a maximum of 40 percent oxygen. The enriched air can be compressed to 232 bar in combination with a high pressure compressor. The percentage of oxygen obtained at the outlet can be adjusted up to 40 percent through a valve accessible directly on the top of the compressor. The oxygen analyzer allows you to check the correct percentage, adjusting it through the appropriate valve. Standard equipment Electrical cabinet Automatic condensate drain 2 analyzers Thermostat 1 membrane % O2 40% High pressure compressor flow rate to be connected 650 l/min 39 m3/h 23 cfm Notes: operating pressure 232 bar / with the use of compressors with lower flow rates the maximum oxygen percentage is always guaranteed. Engine: Electric three-phase 400 V - 50 Hz Engine power: 15 kW - 20 Hp Charging rate: 2,000 l/min - 120 m3/h - 70.6 cfm Working pressure: 12 bar - 175 PSI Net weight (approx.): 324 kg - 714 lb Dimensions (W x D x H): 118 x 80 x 140.5 cm - 46.4 x 31.5 x 55.3 in
