Hydro-jet inflatable boat JT 18

dieselrigidcenter console

Length o.a. 5,68 m Length max. for storage 5,44 m (with front air chamber deflated) Beam max. 2,44 m Height max. at bow 1,18 m Height max. for storage 1,03 m (with folded console, front air chamber deflated and backrest removed) Passengers (C.E. Directive) No. 9 Design category (C.E. Directive) C Engine 170 mHP Volvo Penta diesel Propulsion system Castoldi waterjet unit type Turbodrive 240 H.C. with hydraulic clutch and movable grid Boat weight 1.140 kg (empty with oil and water in the engine and oil in the waterjet) Fuel capacity 112 l Carrying capacity 923 kg Top speed 36 knots light loaded - 31 knots full loaded Construction: Hull: Single skin structure, hand laid Kevlar and vinylester resin Deck, console: Sandwich structure, hand laid glass and isoftalic polyester resin with nidaplast core Stringer System: Sandwich structure, hand laid Kevlar and vinylester resin with polyurethane closed cell foam core Inflatable tube: Hypalon/Neoprene coated polyester fabric 1670 Dtex No. 5 separate airtight compartments
