Heavy haul trailer YH-9
for sailboats245/70R17.5

Add to favorites

Compare this product

Go to the Conolift website for more information

Characteristics

Use

heavy haul

Applications

for sailboats

Wheels

245/70R17.5

Payload

Max.: 24,000 lb
(10,886.22 kg)

Min.: 18,000 lb
(8,164.66 kg)

Overall length

37'00" , 38'00"
(11.3 m, 11.6 m)

Overall width

61 in, 98 in

Lifting height

58 in

Description

10" x 10" x .250" HSS steel tube frame Hydraulic tongue with pintle ring Hydraulic Power: 6.5 HP Honda gasoline engine Pilot operated safety lock-valves on main frame lift Hydraulically operated rear keel support strap 6 adjustable powerboat pads; 3 telescopic cradle bars with fixtures O-ring boss and JIC hydraulic fittings Zinc coated steel hose ends and fittings High strength hydraulic cylinder shafts Stainless steel hardware (nuts/bolts/pins) Nitrogen ride suspension MTO/DOT approved lighting package LED lights with marine grade wiring Rubber fenders Aluminum rims Electric / hydraulic actuated disc brakes Tires: 245/70R17.5 radials (includes spare and carrier) Complete sandblast to white metal, 1 coat zinc primer, 1 coat epoxy high build primer Polyurethane paint – 2 coats of Conolift Red PPG commercial performance paint
