Road trailer YH-12
for boatshydraulic

Add to favorites

Compare this product

Go to the Conolift website for more information

Characteristics

Use

road

Applications

for boats

Other characteristics

hydraulic

Payload

Max.: 30,000 lb
(13,607.77 kg)

Min.: 24,000 lb
(10,886.22 kg)

Overall length

42'00" , 43'00"
(12.8 m, 13.1 m)

Overall width

61 in, 98 in

Lifting height

58 in

Description

10" x 10" x .375" HSS steel tube frame Hydraulic tongue with pintle ring Hydraulic Power: 6.5 HP Honda gasoline engine Pilot operated safety lock-valves on main frame lift Hydraulically operated rear keel support strap 8 adjustable powerboat pads; 3 telescopic cradle bars with fixtures O-ring boss and JIC hydraulic fittings Zinc coated steel hose ends and fittings High strength hydraulic cylinder shafts Stainless steel hardware (nuts/bolts/pins) Nitrogen ride suspension MTO/DOT approved lighting package LED lights with marine grade wiring Rubber fenders Aluminum rims Electric / hydraulic actuated disc brakes Kodiak 12K silver cadmium plated disc brakes Complete sandblast to white metal, 1 coat zinc primer, 1 coat epoxy high build primer Polyurethane paint - 2 coats of Conolift Red PPG commercial performance paint 3 year warranty on frame, 2 years on hydraulic components with 90 days limited warranty on running gear
