Lamp Lengths 2 x 2 foot; 2 x 4 foot
Number of Lamps 2; 3; 4
Lamp Types T5; T5 HO; T8; T12; T12 HO
Voltage 120-277V 50/60 Hz
Lamp Watts T5 - 14W, 28W; T5 HO - 24W, 54W; T8 - 17W, 32W; T12 - 20W, 40W; T12 HO - 35W, 60W
Housing Material Type 5052H32 copper-free aluminum
Lens Material Prismatic DR acrylic
Battery Back-up Optional
Features :
. Integral support tabs to allow for ceiling suspension
. Corrosion-resistant housing and frame
. Multi-voltage electronic ballast resistant to brownouts or voltage and frequency fluctuations
. Filter tube options allow colored lamps to operate on a separate circuit for darken ship mode
. Three- and four-lamp models are provided with two ballasts for independent switching or color effects
. Parabolic louvre option for glare reduction
. Tool-less entry for easy relamping
. Reversible hinged lens frame with captive knurled screws
. Side access plate allows for ease of installation
. Optional self-contained emergency battery back-up ballasts with test switch
. Optional long life T5 lamps available upon request (consult factory)
