AUXILIARY MACHINERY
Generators:
(2) 60 kw driven by DD 6-71
Electrical Power:
220 v, 60 Hz
Bow Thruster:
None
ELECTRONICS
Radars:
(2) Furuno
Radios (SSB):
(1) SEA 235
Radios (VHF):
(1) Standard
Auto Pilot:
(1) Navigation
Hailer/Talkback:
(1) Standard
GPS:
(1) GPS JRC
(1) GPS Garmin
OWING/ANCHOR HANDLING
Tow Winch Type:
Double Drum
Tow Winch Model:
InterCon DD 150
Side-by-Side
Tow Winch Line Pull:
203,000 lbs. @ Stall
Tow Winch Capacity:
4,000 ft. of 1½ inch
Each Drum
Tow Winch Wire on Tow Drum:
2,500 ft. of 1¾ inch
Tow Winch Wire on Anchor Drum:
3,000 ft. of 1½ inch
Stern Roller:
4 ft. diameter
with 4 ft. Live Section
TUG’S MOORING
Windlass:
1¼ inch Single Wildcat
Single Cathead
Anchors:
(1) 1,000 lb. Danforth
Chain:
900 ft. of 1¼ inch
FIRE FIGHTING
On-Ship:
(1) 15 hp @ 200 gpm
Extinguishers:
Full Compliment
ROUTES
Coastwise & Registry
REGISTRATION
Flag:
USA
Home Port:
New York City, New York
Hull Number:
112
Builder:
Service Marine
Year Built:
1974
Call Sign:
WCX9570
