Ship bell EB300 series

electronic

IBUKI EB-300 series Electronic bell is an “all-in-one” alarm bell equipped with the intensive warning LED lamp.Distinct alarm bell tone is generated from the high performance speaker. The sound level of alarm bell is 102dB at 1m,LED lamp has the feature of long life as 40,000hrs. All function is electronically controlled by the solid integrated circuit. Operation voltage is wide range from AC100V,AC220V and DC24V for the safety alarm purpose to the emergency purpose.Under either power source,power consumption is quite low. Compare with the traditional mechanical bells,EB-300 series are long life and maintenance free from the mechanical failure.The unit is linkable using 2 core cable to control the designated zone and area. Each Alarm bell and LED flash has 2 changeable patterns by the operation of DIP switch. Adjustment of pattern setting is easily done at site enable to achieve the flexibility. LED lamp is synchronized flash with alarm bell sound. The material of solid casing is adopted the polycarbonate specially designed for EB-300 series with durability and lightweight.3 variation of mounting fixture are available with standard wall mount and flush mount for indoor use,waterproof wall mount with cable gland for the installation of machinery space and outboard location. Our unique acoustic resonance technology and experience are featured EB-300 series electronic bell for the support of maritime safety.
