Ro-Pax car ferry VILLA DE AGAETE

catamaranhigh-speed

General Particulars Yard No: 052 Designer: Incat Tasmania Pty Ltd. Builder: Incat Tasmania Pty Ltd. Class Society: Det Norske Veritas Certification: DNV 1A1 HSLC R1 Car Ferry “B” EO Length overall: 95.47m Length waterline: 86.00m Beam overall: 26.60m Beam of Hulls: 4.50m Draft: 4.01m Speed: 38 knots at 728 tonnes deadweight 46.7 knots at lightship Note - All speeds quoted at 100% MCR 4 x 7200 kW @ 1050 rpm without deployment of T-foil, with clean underwater parts and in water depths of 10 metres to 50 metres. Capacities Max Deadweight - 718 tonnes Passenger Capacity - 900 persons (including crew) Passenger Deck - located on one level, the Passenger Deck is divided into three lounges: - Aft Lounge with First and Economy Class seating areas, Bar, Male/ Female Toilets, Guides Room, Children’s Play Area and exterior Passenger Deck. - Midship Lounge with seating areas, Kiosk, Food Preparation Area, Disability Toilet/Mothers Room, Shop and Passenger Entry Doors. - Forward Lounge with seating areas, Bar, Male/Female Toilets, Crew Room including Crew Wash Room, Lower Wheelhouse and Passenger Entry Doors. Vehicle Capacity - 330 truck lane metres at 3.1m wide x 4.0m/4.35m clear height plus 80 cars at 4.5m length x 2.3m wide or 260 cars only using optional mezzanine decks. Axle loads - Transom to Frame 47 - 10 tonnes per dual wheel axle or axle groups to suit European standards. Fwd of Frame 47 Ramp A to D - 0.8 tonnes per single tyre/single axle group.
