Beacon buoy SBM 20/30

high seassteelred

SBM Steel Buoys are designed by combining conventional architecture used during several decades with the application of latest technologies in materials and current standards. The high-quality steel for its construction is the same than the one used in the naval field, with a thickness greater than 10 mm. Float diameters available from 2 to 3 meters are submitted to an antioxidation treatment providing maintenance periods above 5 years. They are characterized by their high shock resistance and stability. Metallic parts of the buoys (superstructure and tail) are made from hot-dip galvanized steel, and designed to provide a long service life under harsh marine conditions. They can be customized under client’s request, as well as to be made from stainless steel or marine aluminium. Technical specifications Diameters From 2 to 3 meters Float made from naval steel A-36 Coated with a special anti-corrosion treatment of inorganic zinc based on ethyl silicate. Float with two lifting handles and two mooring Castillete with robust structure of three angular legs Made of steel with special anti-corrosion treatment of inorganic Zinc based on ethyl silicate, coated with polyurethane paint to give the color of the signal Glue or flap with counterweights Made of hot galvanized steel Stainless steel buoy screws. Marine Rubber Fender Belt in Float. Non-slip float top surface Registration of access to the interior of the float to facilitate maintenance work or for filling of foam Designed in accordance with IALA Recommendations
