Gas generator set 6M16

turbinefor ships60 Hz

Continuous compact power with reference performances in its category Global environment care with low exhaust emissions and controlled fuel consumption at any running cycle Simple technology with mechanical injection Life cycle cost efficiency with extended mean time between overhauls (MBTO) Engine and block Cast iron cylinder block, with replaceable cylinder liners Separate cast iron cylinder heads Replaceable valves guides and seats Steel forged crankshaft with 7 bearings Light alloy piston with 3 high performance piston rings Cooling system Fresh / raw water heat exchanger with integrated thermostatic valves and expansion tank Cast iron centrifugal fresh water pump, mechanically driven Bronze self-priming raw water pump, mechanically driven Lubrification system Full flow screwable oil filters Fresh water cooled lube oil cooler Fuel System In line injection pump with flanged electronic speed governor Double wall injection bundle Duplex fuel filters Water separator Intake air and exhaust system Fresh water cooled exhaust gas manifold Turbo blower with insulated turbine housing Electrical system Voltage 24Vdc Electrical starter on flywheel crown 55A battery charger Generator - 50/60Hz Frequency, 4 Pole - Insulation / Heating Class H/H - Electronic voltage regulation - Brushless excitation - IP23 Protection, Marine impregnation - Sealed bearing, life lubricated
