4-stroke engine Powertec 9outboardelectricboating
Add to favorites
Compare this product
Characteristics
- Type
- outboard
- Power source
- electric
- Market
- boating
- Other characteristics
- 4-stroke
- Power
9 ch
(9 hp)
Description
Power, Performance and maximum efficiency.
Ultra Low Emission.
high fuel efficiency.
Lightweight and compact.
Proven technology.
EPA Approved, CE and CARB.
– Easy to transport, easy to install, easy to use
Features
Engine type
2 Cylinder
Displacement
212
Bore & Stroke
56 x 43 mm
Compression Ratio
8.9:1
Prop Shaft Horsepower
9HP @ 5000rpm
Full Throttle RPM Range
4500-5500
Fuel/Induction Systemn
OHV
Intake
Carburetor
Exhaust
Through Proppeler
Cooling
Water / Thermostatic Control
Ignition System
CDI
Alternator Output
6 Amp (Optional: Requiere Charging Kit)
Starting System
Manual
Lubrication
Wet sump
Engine Oil Capacity
600cc
Gear Ratio
(27:13) (2,08)
Gear Shift
Forward, Neutral, Reverse
Shaft Length
S= 15
Degree of Tilt
69 °
Degree of Trim
5 positions
Dry Weight
S:38 kg L:40
Steering Angle (maximum)
90 ° from center, either direction
