Rigid solar panel EDP0SGF120
63 cells

Rigid solar panel - EDP0SGF120 - seatronic - 63 cells
Rigid solar panel - EDP0SGF120 - seatronic - 63 cells
Add to favorites
Compare this product


Characteristics

Structure
rigid
Number of cells
63 cells
Peak power (Wp)

120 W

Voltage at maximum power

37 V

Max power current (Imp)

3.2 A

Open circuit voltage (Voc)

44.4 V

Short circuit current (Isc)

3.9 A

Weight

3,100 g
(109.3 oz)

Length

1,085 mm
(43 in)

Width

63 mm
(2 in)

Thickness

3 mm
(0 in)

Description

VERY HIGH EFFICIENCY CELLS: Sunpower cells are 20-30% more efficient than monocrystalline cells and have the added advantage of being extremely reliable (SunPower PV cells hold the world record for energy production). For example, SUNPOWER solar cells were selected to power the Solar Impulse solar aircraft. MANUFACTURING QUALITY: These solar panels are also manufactured in accordance with ISO9001 and ISO140001 standards to ensure the highest level of quality. TRACEABILITY: Each module is individually tested under ISO conditions and has a unique serial number that cannot be altered to ensure certified quality. INSTALLATION: These solar panels are designed to be glued to the deck. Semi-rigid, they easily follow the curves of the boat with a flexibility of 10%. The fiberglass support ensures resistance to intensive trampling and the ETFE structure provides a non-slip surface. INNOVATION: Thanks to the Optimized Shadow technology developed on the 54W, 120W and 150W panels, in case of shadow on one half, the panel continues to produce at 50% of its rated power. Function - Allows for efficient recharging of batteries from solar energy. The underside of the panel made of fiberglass ensures exceptional resistance. The ETFE coating ensures optimal light transmission to the cells and guarantees the durability of the module. These solar panels are footprint resistant and are intended to be glued to the deck. Panel top material - ETFE (ethylene tetrafluoroethylene): This composite material combined with quality manufacturing makes Seatronic panels extremely robust. They will not be subject to delamination, cracking or corrosion.
