Selector battery switch EA11CBR200A

The battery fuse must be installed for each battery bank, to isolate it from the rest of the installation. Our battery fuse will prevent the risk of a short-circuit that could cause a fire, on your boat or van for example, avoid discharging your battery during prolonged storage, or isolate the wiring harness to make your work safer. Note also that the red button in OUT position is removable, to prevent any unwanted intervention, and will also act as an anti-theft device on your motorboat or yacht. Function - Isolate an installation from batteries Power rating - 200 A Accepted voltage - 12 V / 24 V Max. voltage - 50V DC Peak power - 500 A for 5 sec Connection - 2-pin M8 Operation - With removable handle Dimensions - 61x45 mm Weight - 66 gr Hole diameter - 38mm Mounting - Hexagonal metal nut Operating temperature - -30°C to 60°C
