Diesel generator set 29 GS/GSC
for boats50 Hz

diesel generator set
diesel generator set
diesel generator set
diesel generator set
diesel generator set
diesel generator set
diesel generator set
Add to favorites
Compare this product


Characteristics

Motor type
diesel
Application domain
for boats
Frequency
50 Hz
Output power

28.4 kW
(38.6 hp)

Voltage

230 V

Rotational speed

1,500 rpm
(9,425 rad.min-1)

Displacement

3,331 cm³
(113 US fl oz)

Number of cylinders

4 unit

Length

1,600 mm
(63 in)

Width

740 mm
(29.1 in)

Height

837 mm
(33 in)

Net weight

714 kg
(1,574 lb)

Description

The 29 GS/GSC is a single phase marine generator set assembled on a 4 cylinder Mitsubishi engine block, which performs 28,4 kW - 28,4 kVA at 1500 rpm and 50 Hz. This is the last one from Solé Diesel range available as single phase, perfect for those leisure boats with a certain size and high electrical demand and even that require the marine generator to operate on continuous duty. The sound shield (canopy) version makes the navigation more enjoyable and free of disturbing noises. There is a wide range of kits at disposal, for those boats which requires a demanding configuration. In addition, synchronism for parallel operation, and DNV type approval from IACS, for those boats which demands the highest standards in terms of security.

Catalogs

29 GS/GSC
29 GS/GSC
4 Pages
