Shipyard bending press 2200 CNC

hydraulicCNC

The “2200 CNC” hydraulic horizontal press ticks every box as far as flexibility and the range of performance of the control system are concerned. The CNC control is used primarily for pre-tensioning steel beams. The machine meets the highest requirements of large steel construction companies, which often camber beams, and of steel service centres, which offer bending of steel beams (cambering, pre-tensioning) as additional services. The robust, heavy design of this bending press guarantees precise bending results. The special feature of this horizontal bending press lies in the use of a laser-operated control system, which provides the best possible support for the process of cambering steel beams. The operator can enter the height of the arch numerically. The hydraulic horizontal press then controls the cylinder stroke and the beam feed of the powered roller conveyor in automatic mode. Main application: Cambering (pre-tensioning, cambering) of steel beams Working power - 220 to / 2200 kN Tooling height - 600 mm / 23.62" (inch) Straightening capacity - HEA/HEB 600 Pipe bending - 4" Control - CNC Control Program memory - 200 Measuring precision - +/- 0.1 mm Cylinder speed - 0 - 0.6 m/min continuously controll Motor power - 18.5 kW Voltage - 3x400 V / 50 Hz (other voltages) Weight - 18,000 with 8 m dressing bar Color - NCS 3050 blue-green NCS 4050 wine red Installation - mobil
