The “4400 RP” stationary rail bending and straightening system is used for universal bending and straightening in rail and points construction.
The horizontal design facilitates simple handling and transport of the rails. With the long cylinder stroke, the rails can be machined upright or horizontally. The tool height of 300 mm allows for straightening and bending of all standard rail profiles. As an option, the abutments can be set electro-mechanically to the rail profile required. With the quick-change tool system, the machine can be refitted for a different rail profile very quickly.
The operator is assisted by the manual control with fine stroke adjustment which is easy to operate. An optional laser system supports the operator with bending and straightening the rails:
Bending grooved rails
Bending Vignoles rails
Bending and straightening tongue rails (tongue rail straightening machine)
Bending full-web rails
Bending special rails
Bending rails by folding
Straightening rails
Torsion straightening of rails
Straightening frogs
Working power - 440 to / 4400 kN
Tooling height - 400 mm / 23.62" (inch)
Voltage - 3x400 V / 50 Hz
Color - NCS 3050 blue-green
NCS 4050 wine red
Installation - mobile
