Electric connector AGPU series

marineunderwater2 contacts

​Designed for source firing systems for sealed electrical interconnect where high shock and mechanical survivability is paramount. ​ Benefits: Survives high shock environments, such as those found in seismic surveys Excellent mechanical survivability in extreme environments​ ​Waterproof electrical connectors for high shock extreme applications. Specifications Depth - 300 PSI equivalent (when fully and properly mated) Operational Temperature - 20° F - 158°F Mates/Demates - 100 Voltage Rating - 1500 VDC Current - 8 Amps DC maximum Contact Resistance - 100mΩ maximum (measured in accordance with procedure EIA-364-06C) Vibration - 1000g peak Isolation - 500MΩ at 500 VDC (when measured pin-to-pin or pin-to-shell) Tensile - 500 lbs axial pull​ Applications Buoy systems for sealed electrical interconnect where high shock and mechanical survivability are paramount Diver tools and equipment High shock, excellent sealing, mechanically tough, compact Marine deck systems Compact, mechanically tough, watertight-high pressure wash down survivable, crush resistant Designed for shallow water superior sealing High axial load survivability
