Patrol boat HD420

military boatoutboardrigid hull inflatable boat

Tiger Marine HD Sériés are the backbone of many fleets and hâve been recognized as being simple, strong and reliable. They are made specially to carry heavy loads safely with the best maneuverability speed and capacities . They are also designed to meet the requirements for search and rescue organizations . Ail models are equipped with a heavy duty light weight aluminum floor boards which gives the best rigidity specially with the deep V bottom created by the inflatable keel. Three models are available 4.2, 4.8 and 5.2 meters boats. Made from CSM/Neoprene - Orca Brand with available three fabric Dtex 1100, 1670 and 1880 which is suitable for a hard military use. TECHNICAL SPECIFICATIONS 420HD Length : 4.20 m Width :1.90 m Tube Diameter : 45 cm No. of Persens : 8 No. ofChambers: 5+1 Max. HP:40 HP Shaft Length : Short Floor Type : Aluminum Boat Weight : 95 Kg 480 HD Length : 4.80 m Width : 2.06 m Tube Diameter : 52 cm No. of Persens: 10 No. ofChambers: 5+1 Max. HP : 55 HP Shaft Length : Long Floor Type : Aluminum Boat Weight : 120 Kg 520HD Length : 5.20 m Width : 2.20 m Tube Diameter : 56 cm No. of Persens: 12 No. ofChambers: 5+1 Max. HP : 75 HP Shaft Length : Long Floor Type : Aluminum BoatWeight: 140 Kg STANDARD FEATURES Aluminum Floor boards Transom plates Transom suspension rings two drain plugs Large Transom Drain hose 2 0ars Full length life lines Inflatable Keel Seat protection patchs
