Boat drive shaft universal joint CH Series

The CH Series is the standard for high and maximum torques. CH universal joint shafts are individually designed, that is, they are built to customer specifications. They precisely meet the requirements of the drive. Flanges and flange yokes are available in a very wide range of designs and materials. Ensuring low life cycle costs and high operational reliability were the main focus in developing this series. We were able to achieve this using a special bearing concept based on experience of the design of high-performance universal joint shafts spanning several decades. Our engineers will design a complete drive solution just for you. This means you get engineering and products from a single source: Universal joint shafts, connection components and shaft support systems. This saves time and money when building your machine or system. Technical data Torques with a single load MZ up to 19,440 kNm Torques with a reversing load MDW up to 11,910 kNm Deflection angle up to 15° Rotation diameter of the joints 350 mm – 1,400 mm Connections Flanges with face key Flanges with Hirth coupling Flanges with split sleeves Quick-release couplings Connection components for rolling mills (wobblers) Adapters
